iKey Industrial Force Sensing Resistor Pointing Device

iKey Industrial Force Sensing Resistor Pointing Device

HP-DT-FSR-USB

$435.00
$435.00
Tax included.
*Special order. Please reach out to enterprise@strike.com.au to discuss your needs*

Features

  • No mechanical parts: visible change, improved technology, better accuracy, and smoother use
  • Long life: 420,000 hours – 7x more than the CTS (60,000)
  • Stainless Steel Case

Tech Specs

  • Model Number: HP-DT-USB: With USB cable
  • Dimensions: 4.90" x 4.90" x 1.13" (w-h-d) 124.5mm x 124.5mm x 28.7mm
  • Weight: 1.25 lbs (0.68 kg)
  • Certifications: NEMA 4X, UL60950, FCC Part 15 Class B
  • Shock: 3x11 ms pulses of 50g on each of 3 axes
  • Key Switch:
    • Material: Industrial silicone rubber
    • Life: 10 million cycles
    • Travel: 0.055 in.
    • Actuation Force: 200g (+/- 20g)
    • Feedback: Tactile with mechanical snap
  • Vibration:
    • Power Spectral Density: 0.04g/Hz
    • Frequency Range: 20Hz - 2 kHz
    • Duration of Test Per Axis: 3 hours
  • Power:
    • USB:35mA@5V (from CPU port)
  • Temperature Range:
    • Storage: -40C to +70C (-40F to 158F)
    • Operating: -20C to +60C (-4F to 140F)
  • Cable: USB

Package Contents

  • 1 x iKey Industrial Force Sensing Resistor Pointing Device

Extra Info

View full details

The Force Sensing Resistor is an upgraded pointing device that offers improved sensitivity and increased durability and combines the functionality of a mouse and the flexibility of a joystick in one convenient, small-footprint package. Housed in a sturdy stainless steel case, it provides pressure-sensitive feedback for positive motion control without requiring vigorous movement. The low-profile design contains no protruding parts that might break and no moving elements to collect dust. With its completely sealed NEMA 4X design, the Force Sensing Resistor can withstand spills, washdowns, contaminants and the impacts of an industrial environment.

Strike Group Australia is an Australian Distributor of iKey rugged keyboards and computer peripherals. If you need help confirming what iKey you need, email enterprise@strike.com.au to discuss your solution.
